Technical Specifications
Brand:
MaxLinear
Case/Package:
TSSOP
Mount:
Surface Mount
Number Of Pins:
16
Number of Terminals:
16
Data Rate:
235 kbps
Logic Function:
Transceiver
Low Level Output Current:
1.6 mA
Max Operating Temperature:
70 C
Max Supply Current:
1 mA
Max Supply Voltage:
5.5 V
Min Operating Temperature:
0 C
Min Supply Voltage:
3 V
Nominal Supply Current:
1 mA
Number of Circuits:
2
Number of Drivers:
2
Number of I/Os:
4
Number of Receivers:
2
Number of Transceivers:
2
Number of Transmitters:
2
Operating Supply Voltage:
3.3 V
Temperature Grade:
Commercial
Height:
1 mm
Length:
5 mm
Terminal Pitch:
650 um
