Technical Specifications
Brand:
MaxLinear
Case/Package:
SOP
Mount:
Surface Mount
Number Of Pins:
8
Number of Terminals:
8
Data Rate:
250 kbps
Interface:
RS-422, RS-485
Logic Function:
Transceiver
Low Level Output Current:
1 mA
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
85 C
Max Power Dissipation:
471 mW
Max Supply Current:
1.5 mA
Max Supply Voltage:
3.6 V
Min Operating Temperature:
-40 C
Min Supply Voltage:
3 V
Nominal Supply Current:
800 uA
Number of Circuits:
1
Number of Drivers:
1
Number of Receivers:
1
Number of Transceivers:
1
Number of Transmitters:
1
Operating Supply Voltage:
3.3 V
Packaging:
Tape and Reel
Propagation Delay:
200 ns
Simplex/Duplex:
Half Duplex
Temperature Grade:
Industrial
Height:
1.75 mm
Length:
4.9 mm
Terminal Pitch:
1.27 mm
Width:
3.9 mm
