SM-2924-C012 - 24V 20kg RS485 Serial Bus Servo Motor

Resources:

• Datasheet
• User Guide
• Product Selection Guide

Industrial-Grade RS485 Smart Servo Motor with Brushless Drive and Full Rotation Control

The SM-2924-C012 serial bus servo motor is engineered for industrial automation, robotics, and logistics systems requiring stable torque, precise positioning, and long-term reliability. Supporting both 12 V and 24 V operation, this smart servo uses a high-efficiency brushless motor combined with a steel gearbox and a rugged all-aluminium alloy housing. A Feetech in-house developed RS485 control board and a 12-bit high-precision magnetic encoder enable accurate motion control and robust communication in multi-node industrial networks.

This RS485 servo motor delivers up to 20 kg.cm stall torque and supports 0–360-degree angle control as well as multi-turn continuous rotation mode. Intelligent features such as one-key midpoint setting, programmable acceleration with slow start and stop, and comprehensive real-time feedback enhance system safety and control accuracy. The servo can report position, speed, voltage, current, temperature, and load, enabling effective overload and over-current protection in demanding environments. With a 6T output shaft and industrial-grade construction, it is well suited for robots, conveyor systems, automated equipment, and smart motion platforms.

Key Features

• Industrial RS485 Serial Control
  Reliable RS485 communication for stable multi-device networking in industrial systems
• Brushless Motor with Steel Gearbox
  Ensures high efficiency, long service life, and consistent torque output
• Wide Voltage Compatibility
  Operates on both 12 V and 24 V power supplies for flexible system design
• Full Rotation and Multi-Turn Operation
  Supports 0–360-degree angle control and continuous rotation modes
• Comprehensive Feedback and Protection
  Real-time monitoring of key parameters with built-in overload and over-current protection
