Technical Specifications
Brand:
Seeed Studio
Backhaul:
LoRaWAN (v1.0.4 Class A)
Bluetooth:
Bluetooth v5.1, setting via App
LoRaWAN Channel Plan:
IN865/EU868/US915/AU915/AS923/ KR920/RU864
Temperature:
Range: -20 to 60 C ; Accuracy: ± 1 C Resolution: 0.1 C
Light:
0 to 100%
Antenna:
Internal (GNSS/LoRa/Wi-Fi/BLE)
Communication Distance:
2 to 5km (depending on gateway antenna, installation, and environments)
IP Rating:
IP65
Dimensions:
85x55x6.5 mm
Device Weight:
32g
Operating Temperature:
-20 C to+60 C
Operating Humidity:
5% - 95%
GNSS Constellation:
T1000-A/B: GPS/GLONASS/Galileo/ BeiDou/QZSS, T1000-C/D: GPS/ BeiDou
GNSS Sensitivity:
-145dBm cold start / -160 dBm Tracking
GNSS Location Accuracy:
~1m CEP, GPS, -130dBm
Wi-Fi Positioning:
Passive scanning, uploads the scanned 4 MAC addresses
Bluetooth Positioning:
uploads the scanned 3 best signal MAC addresses of Beacon
Data Cache:
Cache 1000 data when there is no LoRaWAN network
Battey Capacity:
Rechargeable lithium battery, 700mAh
Battery Life Estimates:
4 months on a single charge(uplink every 1 hour, only GNSS data)
Battery Life Monitoring:
Periodic uplink battery level
Charge Cable (Adapter not included):
USB magnetic charging cable, 1 meter
Power Input Voltage:
4.7 to 5.5V DC
Charging Temperature:
0 to+45 C
Data Storage:
Over 1000 location data records store on the device when there is no LoRaWAN coverage
