Technical Specifications
Brand:
Radxa
SoC:
Commercial Rockchip RK3588 / RK3588J Industrial
CPU:
Quad Cortex -A76 @ 2.2~2.4GHz and a Quad Cortex -A55 @ 1.8GHz
GPU:
Arm Mali G610MC4-OpenGL ES1.1, ES2.0, and ES3.2, - OpenCL 1.1, 1.2 and 2.2,- Vulkan 1.1 and 1.2,- Embedded high performance 2D image acceleration module
NPU:
Supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration, Computing power is up to 6TOPs
Multimedia:
H.265 / H.264 / AV1 / AVS2 multivideo decoder up to 8K@60fps, H.264 / H.265 multivideo encoder up to 8K@30fps
RAM:
64bit LPDDR5, 4GB, 8GB, 16GB, 24GB, 32GB
Storage:
1xSPI Flash for Bootloader, 1xOptional Onboard eMMC, 1x microSD Card Slot, 2x M.2 M Key Connector each with PCIe 3.0 2-lane
Audio:
1x4‐ring 3.5mm Headphone Jack with Microphone Input, 1xDigital Microphone via FPC Connector
Display:
1xStandard HDMI 2.1 supporting up to 8Kp60, 1x Standard HDMI 2.1 supporting up to 4Kp60, 1x DP supporting up to 4Kp60 via USB Type C port, 1x 4-lane MIPI DSI supporting up to 1080p60,
Video Input:
1x Standard HDMI Input supporting up to 4Kp60, 2x 4-lane or 4x 2-lane MIPI CSI for camera
USB:
1x USB Type-C port, DP display up to 4Kp60, USB 3.1 Gen1 OTG, 2x USB 3.1 Gen1 Type A HOST port, 2x USB 2.0 Type A HOST port
Ethernet:
2x 2.5 Gigabit Ethernet ports, one with PoE support(Optional Build-in PoE)
Wireless:
Onboard Wi-Fi 6 & BT 5.2 with Dual Antenna Connector(Consume-Grade), Onboard Wi-Fi 6E & BT 5.3 with Dual Antenna Connector(Industrial-Grade)
Mobile Network:
1x M.2 B Key Connector, Standard M.2 3042 B Key modules are supported, 1x SIM Card Socket
Miscellaneous:
1xRTC battery connector, 1x PWM fan connector, 1x Power button, 1x Recovery button, 1x RGB LED for power indicator, system status indicator and custom usage
Power Requirements:
5525 DC Jack Port 12V Input Support, 5V Power applied to the GPIO PIN 2 & 4
Software:
Radxa OS, Android
Dimension:
110 mmx82 mm
