Technical Specifications
Brand:
Seeed Studio
GPU:
1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
CPU:
8-core Arm Cortex-A78AE v8.2 64-bit CPU (Orin NX 16GB)
Memory:
16GB 128-bit LPDDR5 (Orin NX 16GB)
Video Encode:
1x4K60 (H.265) | 3x4K30 (H.265) | 6x1080p60 (H.265) | 12x1080p30 (H.265)
Video Decode:
1x8K30 (H.265) | 2x4K60 (H.265) | 4x4K30 (H.265) | 9x1080p60 (H.265) | 18x1080p30 (H.265)
DL Accelerator:
2xNVDLA v2
Ethernet:
1xRJ-45 Gigabit Ethernet (10/100/1000M)
M.2 KEY E:
1x M.2 Key E for WiFi/Bluetooth module（module not included）
USB:
4xUSB 3.2 Type-A (10Gbps) 1xUSB2.0 Type-C (Device Mode)
Camera:
2xCSI (2-lane 15pin)
Display:
1xHDMI 2.1
Fan:
1x4 pin Fan Connector (5V PWM)
CAN:
1xCAN
Multifunctional Port:
1x40-Pin Expansion header,1x12-Pin Control and UART header
RTC:
1xRTC 2-pin, supports CR1220 (not included)
Power:
9-19V DC
Dimensions:
130mmx120mmx58.5mm
Installation:
Desk, wall-mounting
Operating Temperature:
-10 C~60 C
