Technical Specifications
Brand:
Radxa
SoC:
Amlogic A311D
CPU:
Quad‑core Arm Cortex‑A73 (Armv8) 64‑bit @ 2.2GHz and Dual‑core Arm Cortex‑A53 (Armv8) 64‑bit @ 1.8GHz
GPU:
Arm G52 MP4 GPU- OpenGL ES1.1/2.0/3.0/3.1/3.2,- Vulkan 1.0, OpenCL 2.0
NPU:
Computing Power up to 5 TOPs Support for Deep Learning Frameworks- Tensorflow,- Caffe
RAM:
4GB LPDDR4
Storage:
eMMC: 32 / 64 / 128GB,1xMicro SD Card
Wireless:
WiFi5 with external antenna support, BT 5.0, BLE
USB:
1xUSB 2.0 Type C OTG, 1xUSB 3.0 Type C Host
Display:
1xMicro HDMI 2.0 support 4K@60fps, 1xMIPI DSI
Camera:
1xMIPI CSI camera port
Connectivity:
40 x color user GPIO supporting various interface options:- up to 3 x UART- up to 2 x SPI- up to 3 x I2C- up to 3 x PWM- up to 2 x ADC- up to 22 x GPIO- 2 x 5V DC power in- 2 x 3.3V power in- 2 x 3.3V power pin
Operating Conditions:
Recommended Environmental Temperature: 0 ~ 50 C
Dimension:
65 mmx35 mm
