Technical Specifications
Brand:
Diodes Incorporated
Case/Package:
SOT-23
Contact Plating:
Tin
Mount:
Surface Mount
Number of Pins:
3
Number of Terminals:
3
Weight:
7.994566 mg
Collector Base Voltage (VCBO):
75 V
Collector Emitter Breakdown Voltage:
40 V
Collector Emitter Saturation Voltage:
1 V
Collector Emitter Voltage (VCEO):
40 V
Continuous Collector Current:
600 mA
Current:
1 A
Current Rating:
600 mA
Element Configuration:
Single
Emitter Base Voltage (VEBO):
6 V
Frequency:
300 MHz
Gain Bandwidth Product:
300 MHz
hFE Min:
40
Max Breakdown Voltage:
40 V
Max Collector Current:
600 mA
Max Frequency:
300 MHz
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
150 C
Max Power Dissipation:
300 mW
Min Operating Temperature:
-55 C
Number of Elements:
1
Packaging:
Tape and Reel
Polarity:
NPN
Power Dissipation:
310 mW
Termination:
SMD/SMT
Transition Frequency:
300 MHz
Voltage:
40 V
Voltage Rating (DC):
40 V
Height:
1.1 mm
Length:
3 mm
Width:
1.4 mm
