Technical Specifications
Brand:
Texas Instruments
Case/Package:
TSSOP
Mount:
Surface Mount
Number Of Pins:
16
Weight:
61.887009 mg
Ambient Temperature Range High:
70 C
Data Rate:
250 kbps
Interface:
RS-232
Logic Function:
Receiver, Transceiver
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
70 C
Max Supply Voltage:
5.5 V
Min Operating Temperature:
0 C
Min Supply Voltage:
3 V
Nominal Supply Current:
300 uA
Number of Channels:
2
Number of Drivers:
2
Number of Receivers:
2
Number of Transceivers:
1
Number of Transmitters:
2
Operating Supply Current:
1 mA
Operating Supply Voltage:
5 V
Packaging:
Cut Tape
Simplex/Duplex:
Full Duplex
Supply Type:
Single
Termination:
SMD/SMT
Height:
1.2 mm
Length:
5 mm
Thickness:
1 mm
Width:
4.4 mm
Warranty Information
All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.
