LP24 500V 25A 3Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

CNLINKO

No reviews yet Write a Review
SKU:
131-LP-24-C03SX-03-401
MPN:
LP-24-C03SX-03-401
LP-24-C03SX-03-401 - LP-24 Series 500V 25A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount
Quantity
Unit Price (ex. GST)
1 - 9
₹ 380.00
10 - 24
₹ 342.00
25 or above
₹ 304.00
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹448.40 inc. GST
₹380.00 ex. GST

Technical Specifications

Brand:
CNLINKO
Rated Current:
25A
Operating Voltage:
500V
Number of Pins:
3
Insertion and extraction force:
4.5N Max
Withstanding voltage:
2500V
Contact diameter:
Phi 3.0x3
Temperature and humidity:
-40~+80C; 40C, 85%RH
Mating cycle:
1700 times
Screw torque:
42-53 (N·m)
Contact resistance:
< 1.0mOhm
Protection Level:
IP67
Series:
LP Series
Gender:
Male
Connector Size:
M24
Shell Type:
Metal
Termination:
Solder

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

The LP series is one of the best-selling series waterproof connectors made with high-performance engineering plastics. The quick plug design allows one-hand plug/unplug. The copper needle of the power is adopted gold plated technology, which can resist corrosion and suitable for high low temperatures. LP-24 series connectors have been widely used in a variety of challenging environments and situations, such as audio-visual equipment, medical equipment, industrial control, inspection, and measurement, due to their small size, flexible operation and automatic insertion and removal. Compact components, simple operation, fast and stable connection, IP67 rated outdoor waterproof performance. Satisfy the quality and meet the environmental protection requirements of international industrial equipment.

For the mating part, please click here
