Technical Specifications
Brand:
Texas Instruments
Case/Package:
SC
Mount:
Surface Mount
Number of Pins:
5
Accuracy:
5 %
Max Operating Temperature:
85 C
Max Reset Threshold Voltage:
3.15 V
Max Supply Current:
200 uA
Max Supply Voltage:
7 V
Min Operating Temperature:
-40 C
Min Reset Threshold Voltage:
2.85 V
Min Supply Voltage:
800 mV
Nominal Supply Current:
1.2 uA
Number of Channels:
1
Number of Elements:
1
Number of Voltages Monitored:
1
Output Current:
10 mA
Packaging:
Tape & Reel
Quiescent Current:
1 uA
Reset:
Active Low
Response Time:
70 us
Threshold Voltage:
3 V
Type:
Simple Reset/Power-On Reset, Voltage Detector
Watchdog Timer:
No
Height:
1.1 mm
Length:
2 mm
Thickness:
900 um
Width:
1.25 mm
