Technical Specifications
Brand:
Feetech
Storage Temperature Range:
-20 C～80 C
Operating Temperature Range:
-10 C～60 C
Size:
40.7mmx36.5mmx20.16mm
Weight:
64.5+-1g
Gear Type:
Steel
Limit Angle:
NO Limit
Bearing:
Ball Bearings
Horn Gear Spline:
25T/5.9mm
Gear Ratio:
1/275
Case:
Aluminum
Connector Wire:
30+-0.5CM
Motor:
Core Motor
Operating Voltage Range:
4-9V
Idle Current (At Stopped):
10mA@8.4V
No Load Speed:
0.098sec/60(102RPM)@8.4V
Running Current(At No Load) ::
340mA@8.4V
Peak Stall Torque:
34.2kg.cm@8.4V
Rated Torque:
11.4kg.cm@8.4V
Stall Current:
3.6A@8.4V
Command Signal:
Pulse Width Modification
Control System Type:
Digital Comparator
Pulse Width Range:
500~2500 usec
Stop Position:
1500 usec
Running Degree:
180 +- 5(at 500→2500usec)
Dead Band Width:
≤4 usec
Electronic Protection:
Stall 8 sec
