Electric Rotary Union OD86mm 2ch Air G3/8,1Mpa

SENRING

No reviews yet Write a Review
SKU:
530-3002012
MPN:
3002012
Electric Rotary Union OD86mm with 2 G3/8 air channels rated 1 MPa for pneumatic and mixed electrical transmission
Electric Rotary Union OD86mm features 2 G3/8 air channels rated at 1 MPa and supports mixed electrical signals such as USB, HDMI, Ethernet, RF and servo signals View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹13,288.28 inc. GST
₹11,261.25 ex. GST

Technical Specifications

Brand:
SENRING
Passages:
2 passages
Pipe Size:
10~12mm Pipe(G3/8")
Working Life:
20millions for ref (depends on working conditions)
Max. Speed:
250RPM continuously, 1000RPM intermittently
Working Temp:
-30 C~80 C
Work Humidity:
0~85% RH
Housing Material:
Aluminum Alloy
IP Grade:
IP51
Max. Pressure:
1Mpa, Vacuum -90kPa
Torque:
0.2N.m
Voltage Range:
0~440VAC/VDC
Insulation Resistance:
500MOhm /300VDC
Lead Wire Spec:
AWG17# Silverplated Teflon wire
Lead Wire Length:
standard 250mm(can be customized)
Insulation Resistance:
500VAC@50Hz,6s

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

Datasheet

Electric Rotary Union OD86mm – 2 Channel Air G3/8, 1 MPa Pipe Size 10~12mm

The Electric Rotary Union OD86mm (2ch Air G3/8, 1 MPa) is a heavy-duty, industrial-grade rotary interface designed to simultaneously transmit pneumatic media and mixed electrical signals through 360 continuous rotation. Engineered for high-performance automation systems, this rotary union supports compressed air, steam, vacuum, negative and positive pressure transfer with a maximum rating of 1 MPa, making it suitable for demanding production environments. In addition to pneumatic transfer, it is capable of integrating slip-ring functionalities to carry complex electrical signals such as USB, HDMI, 1000M Ethernet, VGA, DVI, coaxial RF, servo motor signals and industrial bus protocols. With two G3/8 air channels designed for 10–12 mm hoses, the OD86mm rotary union ensures reliable, leak-resistant operation under high rotational loads. Its robust construction and hybrid transmission capability make it ideal for robotic arms, packaging machinery, rotary tables, automation modules, semiconductor tools and mixed-media rotary systems.

Key Features:

  • Hybrid Pneumatic + Electrical Transmission: Supports mixed power and communication signals including USB, HDMI, 1000M Ethernet, VGA, DVI, RF coaxial, servo motor feedback, industrial bus rings and more.
  • 360 Medium Transfer: Enables smooth rotation for compressed air, steam, vacuum, negative pressure and positive pressure systems.
  • High Pressure Rating: Supports up to 1 MPa operating pressure (vacuum: –1.5 kPa); higher pressure options available on request.
  • 2xG3/8 Air Channels: Suitable for 10–12 mm pneumatic pipes, ensuring stable and efficient media flow.
  • Industrial-Grade Durability: Designed for continuous operation across harsh industrial environments.
  • Versatile Applications: Ideal for robotics, automation equipment, packaging lines, rotary actuators, CNC machinery, and mixed-signal rotating systems.
