BZX84J-B6V2,115 - Zener Diode 6.2V 550mW Surface Mount SOD-323F

Nexperia

No reviews yet Write a Review
SKU:
156-BZX84J-B6V2115
MPN:
BZX84J-B6V2,115
BZX84J B6V2 six point two volt zener diode in SOD 323F surface mount package
Quantity
Unit Price (ex. GST)
1 - 9
₹ 7.54
10 - 99
₹ 6.79
100 or above
₹ 6.03
BZX84J B6V2 115 is a 6.2V zener diode with 550mW power dissipation in a compact SOD 323F surface mount package. Suitable for voltage regulation and overvoltage protection. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹8.90 inc. GST
₹7.54 ex. GST
11 people looking at this.

Technical Specifications

Brand:
Nexperia
Contact Plating:
Tin
Number of Terminals:
2
Impedance:
10 Ohm
Max Operating Temperature:
150 C
Max Power Dissipation:
550 mW
Min Operating Temperature:
-55 C
Number of Elements:
1
Polarity:
Unidirectional
Reference Voltage:
6.2 V
Voltage Tolerance:
2 %
Zener Current:
5 mA

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

Datasheet

General Purpose Zener Diode for Stable Low Voltage Regulation in Compact Electronic Designs

BZX84J B6V2 115 is a general purpose Zener diode designed to deliver stable voltage regulation and dependable overvoltage protection in low to medium power electronic circuits. With a nominal Zener voltage of 6.2 volt it ensures controlled clamping for sensitive signal lines reference circuits and control nodes.

This Zener diode is widely used in voltage reference networks biasing circuits and signal protection stages across consumer electronics industrial equipment and portable devices. The SOD 323F surface mount package offers a compact footprint with improved power dissipation making it suitable for high density PCB layouts and automated assembly.

Key Features

  • Stable Zener Voltage Regulation
    Provides a consistent 6.2 volt reference for regulation and protection applications
  • Higher Power Dissipation Capability
    Rated for up to 550 milliwatt suitable for low to medium power designs
  • Fast Transient Response
    Effectively clamps voltage spikes to protect sensitive components
  • Low Leakage Characteristics
    Ensures reliable operation in precision and signal level circuits
  • Compact Surface Mount Package
    SOD 323F package supports space constrained and high density PCB designs
