Technical Specifications
Brand:
Diodes Incorporated
Contact Plating:
Tin
Mount:
Surface Mount
Number Of Pins:
2
Number of Terminals:
2
Weight:
4.904468 mg
Element Configuration:
Single
ESD Protection:
No
Forward Current:
10 mA
Forward Voltage:
900 mV
Impedance:
30 Ohm
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
150 C
Max Power Dissipation:
200 mW
Max Reverse Leakage Current:
100 nA
Min Operating Temperature:
-65 C
Number of Elements:
1
Output Current:
50 mA
Peak Reverse Current:
100 nA
Polarity:
Unidirectional
Power Dissipation:
200 mW
Power Rating:
200 mW
Reference Voltage:
15 V
Reverse Voltage:
10.5 V
Termination:
SMD/SMT
Test Current:
5 mA
Tolerance:
6 %
Voltage Rating (DC):
15 V
Voltage Tolerance:
6.12 %
Working Voltage:
15 V
Zener Current:
5 mA
Zener Voltage:
15 V
Height:
1.2 mm
Length:
1.8 mm
Width:
1.4 mm
