Technical Specifications
Brand:
Nexperia
Contact Plating:
Tin
Number of Pins:
3
Number of Terminals:
3
Ambient Temperature Range High:
150 C
Forward Current:
125 mA
Forward Voltage:
1.25 V
Max Forward Surge Current (Ifsm):
4 A
Max Junction Temperature (Tj):
150 C
Max Operating Temperature:
150 C
Max Output Current:
215 mA
Max Power Dissipation:
250 mW
Max Repetitive Reverse Voltage (Vrrm):
90 V
Min Operating Temperature:
-65 C
Number of Elements:
2
Peak Reverse Current:
1 uA
Reverse Recovery Time:
4 ns
Reverse Standoff Voltage:
90 V
Reverse Voltage:
90 V
Height:
1.1 mm
