Technical Specifications
Brand:
Diodes Incorporated
Case/Package:
SMA
Contact Plating:
Tin
Mount:
Surface Mount
Number of Pins:
2
Number of Terminals:
2
Weight:
64.013223 mg
Average Rectified Current:
2 A
Capacitance:
200 pF
Current Rating:
2 A
Element Configuration:
Single
Forward Current:
2 A
Forward Voltage:
500 mV
Max Forward Surge Current (Ifsm):
50 A
Max Operating Temperature:
150 C
Max Output Current:
2 A
Max Repetitive Reverse Voltage (Vrrm):
40 V
Max Reverse Voltage (DC):
40 V
Min Operating Temperature:
-65 C
Number of Elements:
1
Output Current:
2 A
Peak Non-Repetitive Surge Current:
50 A
Peak Reverse Current:
500 uA
Polarity:
Standard
Reverse Standoff Voltage:
40 V
Termination:
SMD/SMT
Voltage Rating (DC):
40 V
Height:
2.1 mm
Length:
4.6 mm
Width:
2.92 mm
