ADS7830IPWR - 8 Bit Analog to Digital Converter 4, 8 Input 1 SAR IC TSSOP-16

Texas Instruments

No reviews yet Write a Review
SKU:
035-ADS7830IPWR
MPN:
ADS7830IPWR
ADS7830IPWR 8-Bit 8-Channel SAR Analog to Digital Converter IC TSSOP-16
Quantity
Unit Price (ex. GST)
1 - 9
₹ 260.94
10 - 99
₹ 234.85
100 or above
₹ 208.75
ADS7830IPWR 8-bit 8-channel SAR ADC with I2C interface and integrated analog multiplexer. Supports single-ended and pseudo-differential inputs for multi-sensor data acquisition in embedded and IoT applications. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹307.91 inc. GST
₹260.94 ex. GST
19 people looking at this.

Technical Specifications

Brand:
Texas Instruments
Case/Package:
TSSOP
Contact Plating:
Gold
Number Of Pins:
16
Conversion Rate:
70 ksps
Differential Nonlinearity:
0.5 LSB
Integral Nonlinearity (INL):
0.5 LSB
Interface:
I2C
Max Operating Temperature:
85 C
Max Power Dissipation:
5 mW
Max Supply Voltage:
5.25 V
Min Operating Temperature:
-40 C
Min Supply Voltage:
2.7 V
Nominal Supply Current:
750 uA
Number of A/D Converters:
1
Number of Analog Inputs:
8
Number of Bits:
8
Number of Converters:
1
Number of Elements:
1
Number of Inputs:
8
Operating Supply Voltage:
5 V
Polarity:
Unipolar
Power Dissipation:
5 mW
Resolution:
1 B
Sampling Rate:
70 ksps
Signal to Noise Ratio (SNR):
50 dB
Spurious-free dynamic range (SFDR):
68 dB
Supply Type:
Single
Height:
1.2 mm
Length:
5 mm
Thickness:
1 mm
Width:
4.4 mm

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

Datasheet

Compact 8-Bit 8-Channel SAR Analog-to-Digital Converter with I2C Interface for Multi-Sensor Data Acquisition

The ADS7830IPWR is a compact and easy-to-integrate 8-bit analog-to-digital converter designed for multi-channel analog signal measurement in embedded systems. Developed by Texas Instruments, this SAR ADC integrates an 8-channel analog multiplexer, allowing multiple sensors or analog signals to be monitored using a single converter.

The device communicates through an I2C-compatible interface, simplifying system connectivity with microcontrollers and embedded processors. It supports both single-ended and pseudo-differential input configurations, providing flexibility for different signal measurement requirements. With its low power consumption and small TSSOP-16 package, the ADS7830 is well suited for portable electronics, sensor monitoring systems, industrial control applications, and IoT devices where efficient analog data acquisition is required.

Key Features

  • 8-Bit Resolution SAR ADC – Provides reliable analog-to-digital conversion for basic sensor measurement tasks.
  • 8 Multiplexed Input Channels – Supports eight single-ended inputs or four pseudo-differential input pairs.
  • Integrated Analog Multiplexer – Enables sequential sampling of multiple analog signals.
  • I2C-Compatible Serial Interface – Simplifies communication with microcontrollers and embedded processors.
  • Single-Ended or Differential Input Modes – Flexible input configuration for different sensor types.
  • Low Power Consumption – Suitable for portable and battery-powered applications.
  • Wide Operating Voltage Range – Supports flexible system power designs.
  • Compact TSSOP-16 Package – Ideal for space-constrained embedded and industrial electronics.
