The 7Semi ILD213T Opto-isolator Breakout is your solution for safeguarding signal transmission in demanding electrical environments. This module utilizes an infrared LED and phototransistor to create robust electrical isolation between circuits, preventing noise, ground loops, and voltage spikes from disrupting sensitive components. It's a must-have for industrial control systems, power supplies, communication networks, and other applications where signal integrity is paramount.
Key Features:
- Exceptional Isolation: Withstand a minimum isolation voltage of 2500Vrms, providing superior protection for delicate circuitry.
- Rapid Signal Transmission: Ensure timely data flow with a swift 5us response time.
- Wide Compatibility: Seamlessly interface with various microcontrollers and digital devices thanks to its 3.3V to 5V operating voltage range.
- Space-Saving Design: The compact footprint facilitates effortless integration into diverse circuit layouts.
- User-Friendly: Straightforward implementation using standard through-hole or surface-mount soldering methods.
Benefits:
- Uncompromised Signal Quality: Maintain pristine signals despite electrical noise and interference.
- Enhanced System Reliability: Minimize downtime and malfunctions caused by electrical disturbances.
- Component Protection: Shield sensitive electronics from damaging voltage surges and ground loop issues.
- Design Flexibility: Integrate isolation into a broad array of systems.
Applications:
-
Industrial automation and control systems
-
Power supply and energy management circuits
-
Communication networks and data buses
-
Medical equipment
-
Automotive electronics
-
Any scenario demanding reliable signal isolation and circuit protection
