7.0 Inch 1024x600 Industrial Android Display Capacitive with Shell 2GB LPDDR4 + 8GB eMMC

DWIN

No reviews yet Write a Review
SKU:
353-DMG10600T070_31WTC
MPN:
DMG10600T070_31WTC
7.0 Inch 1024x600 Embedded Android Display with Capacitive Touch and Shell – RK3566 Android 11 Industrial HMI Panel
Quantity
Unit Price (ex. GST)
1 - 9
₹ 10,742.00
10 or above
₹ 10,312.32
7-inch 1024x600 Embedded Android Display with capacitive IPS touch, RK3566 processor, Android 11, RS232/RS485/Ethernet, and multiple memory options. Perfect for HMI, IoT, and automation. View full description
  • 100% Original Products
  • GST Invoice
  • Earn 3% Cashback
₹12,675.56 inc. GST
₹10,742.00 ex. GST
4 people looking at this.

Technical Specifications

Brand:
DWIN
Display Size:
7.0 inch
Resolution:
1024×600
Display Panel:
IPS
Touch Type:
Capacitive
View Angle:
85°/85°/85°/85°
Display Area:
155.00mm(W)×87.50mm (H)
Power Supply:
12V 1A DC
Brightness:
250nit
Reserved WiFi Interface:
IEEE 802.11b/g/n, 2.4GHz, Bluetooth
Reserved USB Interface:
USB 2.0 *2 (HOST), Type C *1 (OTG)
RTC:
Accuracy: ±20ppm @25℃
User Interface:
10Pin_3.81mm vertical socket, power interface (3PIN_Φ2.0DH)

Warranty Information

All the products supplied by Evelta are genuine and original. We offer 14 days replacement warranty in case of manufacturing defects. For more details, please visit our cancellation and returns page.

Description

Resources:

Datasheet

7.0 Inch 1024x600 Embedded Android Display with Capacitive Touch and Shell: Compact Industrial-Grade Solution for HMI and IoT

The 7-inch Embedded Android Display is a powerful, compact, and industrial-grade display terminal built on the RK3566 Quad-core ARM Cortex-A55 processor (1.8GHz). Running Android 11, it offers smooth performance and long-term reliability for automation, HMI panels, kiosks, and IoT applications. Featuring a 1024x600 IPS screen with wide viewing angles and capacitive multi-touch (G+G tempered glass), it delivers responsive interaction and durability in demanding environments. Available with 2GB/8GB default memory and optional 4GB/32GB or 8GB/256GB configurations, it ensures flexibility for a range of industrial and embedded use cases. With built-in RS232, RS485, and Ethernet interfaces, this display easily connects to external equipment and networks for seamless integration.

Key Features:

  • High-Performance Processor: RK3566 Quad-core ARM Cortex-A55 @ 1.8GHz for fast, stable operation.
  • Operating System: Runs on Android 11, optimised for industrial and IoT environments.
  • Compact Display: 7-inch IPS panel with 1024x600 resolution and wide viewing angle.
  • Capacitive Multi-Touch: G+G structure with tempered glass for accurate touch and durability.
  • Memory Options:
  • Default: 2GB LPDDR4 + 8GB eMMC.
  • Optional: 4GB LPDDR4 + 32GB eMMC or 8GB LPDDR4 + 256GB eMMC.
  • Industrial-Grade Reliability: Built with robust motherboard design for long service life.
  • Connectivity: Integrated RS232, RS485, and Ethernet ports for external device communication.
  • Compact & Durable Design: Includes protective shell, ideal for embedded and HMI systems.
