6x10 RGB WS2812 Matrix XIAO – Seeed Studio
The 6x10 RGB WS2812 Matrix XIAO is a compact and vibrant RGB extension board designed specifically for the Seeed Studio XIAO series. Equipped with a total of 60 WS2812B addressable LEDs arranged in a 6x10 matrix, this module delivers rich, dynamic and full-colour lighting effects suitable for creative projects, wearables, visual indicators and compact display applications. Each LED integrates an RGB chip and control circuit within a 1010 component package, enabling precise pixel-level control through a single data pin. Its ultra-small 21x17.5 mm footprint adopts the classic XIAO form factor, allowing smooth integration into space-limited builds. The board supports multiple matrix extensions through sequential splicing with an additional power supply, making it ideal for scalable lighting installations. Fully compatible with all Seeed Studio XIAO boards and Adafruit QT Py, this matrix offers unmatched creativity and flexibility for interactive and visually expressive projects.
Key Features
- 60 RGB WS2812B LEDs: 6x10 matrix providing brilliant full-colour lighting with independently addressable LEDs.
- Splice Extensions Supported: Allows connecting multiple matrices in sequence using an external power supply for larger displays.
- Thumb-Sized Compact Design: Measuring just 21x17.5 mm, perfect for wearables and tight-space projects.
- Integrated WS2812B LED Technology: RGB chip and control circuit combined in 1010 components for smooth pixel-level control.
- XIAO & QT Py Compatibility: Works seamlessly with all Seeed Studio XIAO boards and Adafruit QT Py for diverse development possibilities.
Applications:
- LED appearance, scene lighting
- LED point light source, LED pixel screen
- All kinds of electronic products and electrical equipment marquee
- Wearable devices
- Mobile equipment
Package Content:
- 6x10 RGB Matrix for XIAOx1
- 7-pin female headerx2
